Embedded QR Code Reader Mini Barcode Scanner Module Kiosk for Vending Machine

Embedded QR Code Reader Mini Barcode Scanner Module Kiosk for Vending Machine

    • Embedded QR Code Reader Mini Barcode Scanner Module Kiosk for Vending Machine
    • Embedded QR Code Reader Mini Barcode Scanner Module Kiosk for Vending Machine
    • Embedded QR Code Reader Mini Barcode Scanner Module Kiosk for Vending Machine
    • Embedded QR Code Reader Mini Barcode Scanner Module Kiosk for Vending Machine
  • Embedded QR Code Reader Mini Barcode Scanner Module Kiosk for Vending Machine

    Product Details:

    Place of Origin: Guangzhou, China
    Brand Name: xeumior
    Certification: CE, RoHS, FCC
    Model Number: MN700

    Payment & Shipping Terms:

    Minimum Order Quantity: 10 pcs
    Price: Negotiated
    Packaging Details: Normal craft paper and foam
    Delivery Time: 3 - 7 days
    Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram,paypal
    Supply Ability: 5000pcs per month
    Contact Now
    Detailed Product Description
    Item: Mini Barcode Scanner Color: White
    Light Source: White LED Interface: USB, RS232,TTL , RS485, Wiegand
    Sensor: 640X480 CMOS Decoding Ability: 1D, 2D And QR
    Dimension: 50mmx50mmx30mm

    Embedded QR Code Reader Mini Barcode Scanner Module Kiosk for Vending Machine





    Features



    New generation, compact module for fixed-mount applications with the latest decoding core, provides a powerful scanning performance for all 1D, PDF, and 2D barcodes on mobile phone screens or on paper.


    Provides a plug-and-play, integrated module solution for verifying barcodes, collecting payments, and billing customers.


    Designed with a wide viewing angle and shallow depth of field to help ensure optimized performance for reading screen barcodes in near field. The broad decoding capabilities include rapid decoding of all 1D and 2D barcodes with particularly powerful reading capability of highly- reflective mobile phone screens, reducing process time and helping to improve the user experience.


    Operates with white LED illumination to improve the reading performance of label barcodes in a low lighting environments. It is one of the very few 2D modules which has optimized performance for both screen barcodes and label barcodes,reducing customer cost and helping to improve the user experience.



    Application



    1.Automatic gate, Access control system

    2.Ticket Vending Machine

    3.Vending Machine

    4.Garbage sorting bin

    5.Manufacturing

    6.Warehouse & Logistics

    7.Hospital Self-service machine

    8.Parking lot

    9.Payment terminal







    Specification:





    Performance Sensor 640*480 CMOS
    Symbologies 1D EAN-8,EAN-13,EAN-13 2 add-on, EAN-13 5 add-on,ISSN,ISBN,UPC-A,UPC-E,Code 32,Code 39,Code 93,Code 128,Codabar,Industrial 2 of 5,Interleaved 2 of 5,Matrix 2 of 5, GS1 DataBar(RSS14), GS1 DataBar Limited,GS1 DataBar Expanded,ISBT-128,GS1-128,code39FULLASCII
    2D PDF417,QRcode,MicroQR,Aztec,Datamatrix



    Depth of field

    Tested Code Min Max
    UPC-13mil 1cm 8cm
    20 mil code39 5cm 9cm
    20 mil QR Code 0cm 6cm
    OS Linux,Android,Windows XP, 7, 8,10,MacOS
    Scan Mode Auto Scan , command scan
    Countires Keyboard English, French, Italian, German, Spanish, Finnish, Japanese, Russian, Arabic, Irish, Polish, Dutch, Czech, Portuguese (Portuguese, Brazilian), Swedish, Turkish (F, Q ), Greek, Belgian (French)
    Min resolution Code 39 5mil
    Decode capacity 1D/2D Codes on printed paper and mobile screen
    Min Print contrast 35%
    Second development By serial command
    Envoirnmental Drop Withsand drop from 1.5 meters 5 times
    Sealing IP54
    Operating Temperature 0-55℃
    Storage Temperature -20-60℃
    Operating Humidity 5-95% Non condensing
    Storage Humidity 5-95% Non condensing
      Indication LED, BEEPER

    Physical



    Net Weight 64g
    Gross Weight USB:195g/RS232:270g
    Dimension 50mm*50mm*30mm
    Packing Dimension 185mm*101mm*52mm
    Cable Length 180cm±3cm
    Interface USB,serial(TTL,RS232,RS485),weigand
    Voltage 5V
    USB Standby Power 118mA/0.59W RS232 Standby Power 118mA/0.59W
    Operating Power 149mA/0.745W Operating Power 149mA/0.745W
    MAX Power 151mA/0.755W MAX Power 151mA/0.755W
