Fixed Mount 2D Barcode Scanner Module QR Code NFC Reader for Access Control Kiosk

Fixed Mount 2D Barcode Scanner Module QR Code NFC Reader for Access Control Kiosk

    • Fixed Mount 2D Barcode Scanner Module QR Code NFC Reader for Access Control Kiosk
    • Fixed Mount 2D Barcode Scanner Module QR Code NFC Reader for Access Control Kiosk
    • Fixed Mount 2D Barcode Scanner Module QR Code NFC Reader for Access Control Kiosk
    • Fixed Mount 2D Barcode Scanner Module QR Code NFC Reader for Access Control Kiosk
  • Fixed Mount 2D Barcode Scanner Module QR Code NFC Reader for Access Control Kiosk

    Product Details:

    Place of Origin: Guangzhou, China
    Brand Name: xeumior
    Certification: CE, RoHS, FCC
    Model Number: MN828

    Payment & Shipping Terms:

    Minimum Order Quantity: 10 pcs
    Price: Negotiated
    Packaging Details: Normal craft paper and foam
    Delivery Time: 3 - 7 days
    Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram,paypal
    Supply Ability: 5000pcs per month
    Contact Now
    Detailed Product Description
    Item Name: QR NFC Reader Light: White Led Light
    Sensor: 640X480 CMOS Dimension: 65mmx61mmx26mm
    Weight: 30 G Interface: USB, RS232,TTL ,Wiegand

    Fixed Mount 2D Barcode Scanner Module QR Code NFC Reader for Access Control Kiosk



    Features



    1.Multople interface: USB, RS232, Wiegand, RS485, TTL

    2.Mini size 61x65x26mm

    3.Auto scanning

    4.1D, 2D and QR code.

    5. NFC reader





    Application



    1.Access control system

    2.Bank queuing number machine

    3.Vending Machine

    4.Metro gate machine

    5.Manufacturing

    6.Warehouse & Logistics

    7.Hospital Self-service machine

    8.Parking lot

    9.Payment terminal

    10.Industrial assebly line





    Specification:



    Performance
    Image Sensor
    640*480
    Light Source
    White LED
    Scan Angle
    Skew±70° Pitch±70° Roll 360°
    FOV
    Dio87.1° Horizontal 74° Vertical 65°
    Mini Resolution
    ≥5mil
    Barcode Minimum Print Contrast
    ≥20%
    Decode Capacity
    1D
    Codabar,Code 11,Code 128,Code 39,Code 93,EAN-8,EAN-13,GS1 DataBar,UPC-A,
    UPC-E,Interleaved 2 of 5,Industrial 2 of 5,Matrix 2 of 5,
    Straight 2 of 5 IATA,MSI Plessey
    2D
    Aztec Code,HANXIN,Maxicode,
    Codablock F,Data Matrix Code(DPM),PDF417,Micro PDF417,QR Code,Micro QR Code,DOT Code,Grid Matrix Code
    Typical Decode Range(Typical)
    Code39(5mil)
    20mm~60mm
    Barcode Size:25mm*10mm
    EAN-13(13mil)
    10mm~100mm
    Barcode Size:31mm*17mm
    QR(15mil)
    5mm~90mm
    Barcode Size:8mm*8mm
    RFID Range(Typical)
    NFC
    0mm-40mm
    Physical
    Interface
    USB / RS232/485/Wiegand/TTL
    Voltage
    4.8 VDC-16 VDC
    Current(Typical)
    300mA(5 VDC)
    Current(Max)
    400mA(5 VDC)
    Standby Current
    130mA(5 VDC)
    Power Consumption(Typical)
    1500mW
    Dimension
    61(W)×64.8(D)×26(H) mm
    Color
    Black
    Net Weight
    30g
    Country Keyboard Layout
    Multi-Countries Keyboard Layout
    Indicator
    LED, Beeper
    Environmental
    Operating Temperature
    0℃ ~ 50℃
    Storage Temperature
    -20℃ ~ +70℃
    Humidity
    5% ~ 95%(Non-Condensing)
    ESD
    EN61000-4-2,
    ±15KV Air Discharge,±8KV Contact Discharge
    Ambient Light
    0~100,000LUX
    LED Safety
    IEC 62471
    Accessories (Optional)
    USB Cable
    Data Transmission, Power Supply,
    RS232+Power Adapter
    Data Transmission, Power Supply
    485 / Wiegand Cable
    Data Transmission, Power Supply
    EVK+12P FPC+Power Cable
    Data Transmission, Power Supply
