Portable Mini Bluetooth Handheld Mobile Android Bluetooth Thermal Printer for Lottery
Advantages of handheld printer
* 57x30mm thermal paper roll
* Support:USB,Bluetooth,Wifi,3G
* Provide US, EU, AU, UK plug
* Compatible android, ios and windows
* Language:Chinese,English French,Spanish,Russian,Genmany etc.(Support multiple languages)
* Battery:7.4V 1500mAh
* Free software,SDK
* Small design, convinient and easy to take out for printing
* Support android & IOS
* High speed printer, print at anywhere and anytime
Advantage Characteristics
Item Name:Thermal Bluetooth Receipt Printer
Print Method:Thermal Line Printing
Print Speed :90mm/s
Reliability:100km
Resolution: 203dpi(8dot/mm)
Print Width :48mm(84 dot)
Paper Width: 58±01mm
Roll Diameter: φ≤40mm
Paper Type: Thermal Paper
Power(Optional):rechargeable lithium battery
Battery:Lithium( 7.4VDC/1500mA) ;
Charging mode:DC 9V/1.5A
Weight:174g (battery)
Dimension :10.5 * 7.8 * 4.8cm (L * W * H)
Print Command: Compatible with ESC/P0S/STAR
Interface: standard RS232/USB, Bluetooth 2.0/SPP agreement or infrared /IRCOMM agreement(optional).
support to download the Logo trademark
Working Temperature: -10~50°C;
Contrast Humidity: 10-90%
Application:
The mobile police system
The tobacco distribution system
The utility meter reading system
The mobile office / mobile logistics systems
The portable instrumentation
The testing equipment, ancillary equipment.
Low operating costs (no ribbons, ink cartridges)
| Overall Dimension (W×D×H) |
105×75×45mm |
| Weight |
134g |
| Color |
Black |
| Effective print width |
48mm |
| Print method |
Thermal line printing |
| Print commands |
ESC/POS compatible command set |
| Print speed |
Up to 90mm/sec |
| Resolution |
8 dots/mm(203dpi) |
| Print font |
12x24/ 24x24 |
| Column capacity |
32 columns/ 16columns |
| Character size |
1.5 x 3.0 mm(W x H)/ 3.0x3.0mm(WxH) |
| Paper dimensions |
58.0±0.1mm x diameter 40.0mm |
| Paper thickness |
0.06 to 0.08mm |
| Character set |
Alphanumeric/ Chinese Kanji |
| Interface |
USB, RS-232,Bluetooth (optional) |
| Data buffer |
Up to 5K bytes |
| Power Adapter |
9V DC/2A |
| Battery Power |
7.4V DC/ 1500mA; battery can stay by for 4-5 days, when it is full power, it can print 120-150m paper |
Basic Info and Key Features
It applies mobile products to supporting the use, and suitable for outdoor work environments
small in size,light weight,reliable performance,simple to connect, easy to use
Low operating costs(No Ribbons or ink cartridges)
High-speed , long life-span and high quality . Suitable for all types of commercial retail POS systems
Working time :
High capacity rechargeable lithium battery and standby time 5-6 days
Fully charge ( No stop printing 120-150m thermal roll , 20-25pcs rolls at 58 *30mm in dimension )
Languages :
Multi languages support , more than 73 languages
simplified Chinese/ Taiwan or HK Traditional( complex font) or international languages
Many interfaces available( serial / usb / Bluetooth )
RFQ:
Q: Can you make OEM or ODM for products?
A: OEM and ODM products are available for customers, as long as customers meet the MOQ. Also we have engineers for logo and products design for customers.
Q: What about delivery time?
A: Samples within three working days and bulk order within one week after received payment.
Q: What waranty and after-sale service do you offer?
A: 1 year warranty. During warranty period, the damage caused by non-human factor, we will be responsible for the free repair. Overdue warranty period,we will continue to provide services with reasonable price to the customer.
Q: How about the shipping way?
A: There are DHL,FEDEX,TNT,UPS,EMS,air cargo, by sea(we also can ship goods by your shipping account or other agent you proivded)
